PCB circuit board quotes vary depending on the material, process, number of layers, and other factors, and it is impossible to generalize. However, the PCB circuit boards offered in the store are known for their high quality and reasonable prices.
Material Selection
Base materials: FR4 grades (Shengyi > Kingboard > Guoji)
Thickness options: 0.2-3.0mm (+5-8% cost per 0.2mm increment)
Copper weights: 1/2OZ to 3OZ (35μm-105μm), +40% cost per weight doubling
Surface Finishes
Price ladder: OSP (cheapest) → HASL → ENIG → Gold plating (premium)
Eco-premium: Lead-free processes cost 15-20% more
Design Complexity
Micro-vias: <0.2mm holes add 30% drilling cost
Trace precision: < 4 mil line/space increases price by 50%
Special features: Blind/buried vias start at $30/m² extra
Copper Thickness
Standard: 1OZ (35μm) included
Upgrades: Each additional 1OZ adds 25% cost
Additional Cost Components
Quality Standards
IPC Class 2 (consumer) → Class 3 (industrial) → Military (2× price)
Tooling & Testing
Bulk orders: $150+ mold charge (>500pcs)
Testing fees:
Flying probe: $15-60/design
Test fixture: $150-220 (reusable)
Payment Terms
3-5% discount for cash payments
Order Parameters
MOQ pricing: <10m² priced as prototypes (+300%)
Rush service: 24-hour turnaround doubles base price
Instant Quote Guide
Pricing Formula:
Total Cost = Base Material + (Area × Process Factor) + Special Features
Price Benchmarks:
| Type | Prototype | Volume (>50m²) |
|---|
| 2L 1.6mm | $75/m² | $50/m² |
| 4L | $180/m² | $120/m² |
| 6L | $270/m² | $180/m² |
Lead Times:
- 2L: 3 days (24hr rush +$30)
- 4L: 5-7 days (72hr rush +$90)
